Translation door product overview:
Intelligent translation gate is mainly used to prevent pedestrians from illegally drilling or climbing through the place of the implementation of entrance and exit control management of high-tech products, the shape of the national standard stainless steel profile, fine technology, complete functions, beautiful, rust-proof, durable, resistant to external damage, the equipment will mechanical, electronic, microprocessor control and integrated electronic ticket system, access control test system, Integration and application of parking system, face recognition system, anti-static, fingerprint, palm print, iris and other biometric identification systems.
Product parameters:
Anti-static translation gate forbidden passage
Electrostatic Tester 50556-SmartLog Pro Electrostatic access control system
English name: SmartLog Pro ESD Data Acquisition System
Product description: Employee identification, ESD test, access control, record report, touch screen display specific value
Control software: SQLESDQ2
Product brand: Aegir
Product origin: China
Order number: 50556
Sales unit: set
Moq: 1
· Swipe card, recognize face or fingerprint, test whether the wrist strap and shoe grounding are qualified, control the access control according to the test results, and record the test data at the same time
· 8-inch touch display, showing test results and specific readings
· Simultaneously test and save resistance values and employee information
· Touch screen setting test range (upper/lower limit)
· Built-in sensor card and barcode card reader
· Connect multiple devices through LAN, and set the IP address of each device to upload 60,000 records in less than 15S
· Relay dry contact to control access control or external alarm device
· ESD test record, attendance record, send report and other functions
· Built-in perpetual calendar accurate timing, can be automatically timed through the network
· Can store 1 million brush card records, 1 million list capacity, and no loss of power failure data
· Abundant I/O ports, which can be used to control other external devices
· Used by large enterprises, tested by mass data, stable and reliable performance
Functional features:
1. With fault self-test and alarm prompt function, easy to maintain and use;
2. The operating status of the device can be programmed through the built-in small press disk on the main control board;
3. Mechanical structure anti-clip, anti-collision function, in the case of anti-clip infrared is covered, the swing arm automatically opens again to prevent clamping to people or items, the default delay after reset (until reset), and the force is very small (≤2Kg);
4. Anti-impact function, when no opening signal is received, the door body automatically locks;
5. Door body synchronization adjustable (for double gates);
6. With automatic reset function, the system will automatically cancel the user's permission to pass within the specified time after opening the room;
7. Adjustable normally open or normally closed to meet the requirements of different sites;
8. Can be connected with a variety of reading equipment, receive relay switch signal work;
9. Unit to or two-way control personnel entry and exit;
10. Remote control and management can be achieved directly through the management computer;
11. Delay automatic reset, the standard is 3 seconds after opening automatic reset;
12. The power door body automatically opens, and the power-on automatically closes, which meets the fire protection requirements.
13. Sound (light) alarm function, including illegal entry alarm (reverse entry switch), etc.;
14. Counting function (optional);
15. Anti-clip function (2 pairs of infrared);
16. Accurate logic judgment, infrared reset function (6 pairs of infrared)
17. Voice output, humanized prompt correct passage (optional));
18. You can use the remote control to set the brake machine to operate in the normally open or normally closed state;
19. There is a light indicator at the door (color can be customized according to customer requirements).
Technical parameters:
1. Chassis material: domestic standard (No. 304) stainless copper thickness 1.5mm
2. In and out direction: Unit direction or two-way
3. Working voltage: AC220 10%v/ 50%Hz
4. Drive motor: DC brush motor (24v)
5. Input interface: dry contact signal or 12V level signal or 12V pulse 1 medium signal with pulse width ≥100ms, driving current ≥10mA
6. Communication interface: RS485 standard distance height ≤1200 m
7.LED indicator: 2
8. Read card window: 2
9. Working temperature: -10℃ -50 ℃
10. Relative humidity :≤90%, no condensation
11. Working environment: indoor, outdoor (shade)
12. Speed: 40 people/min (normally open), 25-30 people/min (normally closed)
13. Gate opening and closing time: 1-2 seconds
14. Time required to enter the passable state after power-on: 3 seconds
15. Automatic reset time after failure: 10 seconds
Scope of application:
◇Station, wharf, construction site, school, supermarket entrance control management
◇Exhibition, natatorium, tourist attractions and other ticketing entrance control management
◇Enterprises and public institutions attendance, access control, consumption air access control management
◇Special air access control
