Device description:
AEGIR50556 intelligent electrostatic tester is used to test whether electrostatic bracelets and ankle bracelets meet the standards of electrostatic protection tools, and generate electronic files combined with personnel identification cards and upload them to the server, which is convenient for customers' audit and production department management. AEGIR50556 is a precision test instrument that needs to be corrected regularly (once a year).
50556 Kit:
• Host electrostatic tester
• Stainless steel foot plate (left/right foot separation)
• 12VDC universal power adapter (100-240VAC input power)
• Ground cable
• Test meter and pedal connection cable
• Operating instructions
Product features:
• Support network communication, can upload 60,000 records in less than 15S
• Online upgrade via the network (cross-domain upgrade possible)
• All parameters are set on a PC and can be controlled remotely
• Built-in perpetual calendar accurate timing, can be automatically timed through the network
• Can store 1 million brush card records, 1 million list capacity, and power failure data is not lost
• Abundant I/O ports for controlling other external devices
• Used by large enterprises, mass data test, stable and reliable performance
Basic specifications of electrometer:
|
Protocol standard： |
ISO15693、ISO14443A |
|
Operating frequency： |
13.56MHz |
|
Communication interface： |
RJ45（TCP/IP） |
|
External power supply： |
DC12V/3A |
|
Power consumption： |
＜2W |
|
Display screen： |
LED liquid crystal display screen |
Physical parameters of electrometer:
|
Overall dimensions： |
215*295*60mm |
|
Machine weight： |
2kg |
|
Housing material： |
304 the whole machine does not embroider steel |
|
Protection level： |
IP53 |
Environmental parameters of electrometer:
|
Working temperature： |
-20℃～+70℃ |
|
Storage temperature： |
-30℃～+80℃ |
|
Storage humidity： |
5%～95% No condensation |
Measuring standard of electrometer:
|
Electrostatic bracelet： |
Low limit (100k.750K±10%) High limit (10M±10%) |
|
Anti-static shoes： |
Low limit (100k.750K±10%) High limit (35M.100M.1000M±10%) can be selected |
