Product features:
Ø The use of industrial 32-bit ARM chip, the rest of the devices are industrial devices to ensure the stable operation of the system, fast response speed, greatly improved processing capacity.
Ø The Angle encoder and the electronic clutch device detect the whole gate operation state.
Ø The whole system runs without any mechanism positioning device, and there is no mechanical collision during operation.
Ø With single-stage locking function.
Ø CNC machining technology, fine surface treatment, strong corrosion resistance.
Ø Belt pass automatic prompt function, two level deflection Angle can be set by the customer.
Ø Support fire alarm signal access.
Ø With a key setting often open line function.
Ø Standard configuration for power free passage.
Product performance:
Ø Angle detection and control by Angle encoder, greatly improving the accuracy of swing Angle.
After swiping the card, the swing arm opens, prompting pedestrians to pass, and the swing arm automatically closes after people pass.
Ø Anti-impact function: In the case of not receiving the opening signal, the swing arm is not opened, if forced into, the swing arm turns a certain Angle buffer, immediately lock and emit a buzz alarm sound, 3 seconds after the automatic return to the closed state; Completely avoid the traditional swing brake swing arm fracture, movement damage problems.
Ø Anti-reverse, after swiping the card, only allow pedestrians to travel in one direction; If it passes in the opposite direction, an alarm will be issued, and in some cases the swing arm will quickly close.
Ø The speed can be adjusted according to the requirements of different places, and the internal button can adjust the display of the digital tube
After obtaining the permission to pass the gate, if the gate is not passed within the set time, the permission will be automatically cancelled and restored to the initial state.
Ø Using digital infrared detection to determine various traveling states.
After power off, the swing arm automatically opens the channel in a free passage state to meet the fire protection requirements.
The personnel access gate is compatible with the access control software and is authorized by the access control software.
After swiping the card, you will not pass the gate within 10 seconds by default. If you want to pass again, the swing arm will be locked.
Ø The gate has signal memory function: when the signal is input repeatedly, the gate has memory function, which can improve the traffic speed when the passenger flow is relatively large.
Ø The operating state of the device can be set through the built-in small button on the main control board.
Ø Manual unlock, in case of power system failure, with manual mechanical unlock function, so that it can be two-way traffic.
Ø Standard external electrical interface, with photoelectric safety isolation.
Ø In and out of the two electromechanical gas interlock, one direction during work, the other direction shielded. For entry authorization, personnel can only enter from outside, and for exit authorization, personnel can only enter from inside. The entry is preferred when the entry is authorized at the same time.
Ø Up to 16 traffic modes can fully meet the needs of 99% of domestic management sites.
Ø The security level is AA.
System Management:
Ø Standard access control management: TCP/IP management, TCP/IP communication, multi-level lightning protection, surge protection, card capacity of 30,000, external Wiegand (Wiegand) card reader, to achieve two-way access to the card, all Wiegand (WiegAND) interface compatible with 26, 34, 37 protocols, with optical coupling protection, can install network cameras, with Web maps, It can realize real-time network monitoring and video capture.
Cloud channel system management and visitor registration management:
Ø Cloud channel management system and visitor registration management are closely integrated, through the visitor system terminal authorization access, gate management of visitors in and out, to achieve orderly control.
Ø Cloud access control hardware set control motherboard, card reading module, Bluetooth module, two-dimensional code scanning module in one, to achieve the display of traffic status; Flash reminder and buzzer reminder when swiping card.
Ø Support IC/ID card swipe door opening, mobile APP door opening, QR code door opening, barcode door opening, password, card + password, finger vein second generation card, LED screen display, LCD screen display, support all data query and management through the cloud platform.
Application site
Ø Government agencies, financial institutions, high-end office buildings, hotels and guesthouses, enterprise office buildings, research sites, industrial parks, leisure and entertainment venues, etc.
Product parameters:
