Product parameter：
Suzhou air shower door access control factory direct sales;
Access control card control air shower, specialized management of strict workshop Settings system. This system can effectively manage the effective access and attendance of the staff inside the workshop; You can set "password input", "fingerprint attendance", "swipe card entry" and other forms respectively. The induction control air shower room is widely used in the outside door of the air shower room workshop with high confidentiality, and the personnel need to carry out identity authentication such as swiped card before entering. Workers do not need to swipe cards when leaving the workshop, only need to press the internal bounce one-way switch to achieve internal unlock.
There is no need to swipe the card when leaving the workshop, only need to press the internal bounce one-way switch to achieve internal unlock.
This set of access control system adopts ID card and IC card, which can be used with the original access control card of the customer company, and the number of access control cards can be increased at any time, and the new card can be magnetized or removed at any time. The access control system adopts advanced integrated control electrical system. If you forget your password or lose your magnetic card, you can reset it. For specific operation, remove the back cover of the access control system, there is a "reset" button, use a screwdriver or other sharp object to hold it for 2-3 seconds, and the password will be repeated as the initial password (please refer to the instructions for specific initial password).
ESD anti-static access control system structure features:
Human comprehensive tester: Is the core component of ESD access control, by testing the resistance of the human body indirectly reflects the static indicators of the human body, so as to ensure that the tested person wearing shoes, wristbands and other qualified, while output signals to subsequent components to drive the channel mechanism, according to the group signal of the central controller, It can be used to measure the hands and feet of the card reader, only measure the hands and only measure the feet, and do not need ESD detection.
Three roller gate, entry direction configuration ESD detector and induction card reader, card and electrostatic detection can pass one person. The outgoing direction is also equipped with an inductive card reader for the company to set up a two-way channel. The exit gate is equipped with an outgoing sensing card reader, which can be set to swipe the card to go out or set to go out freely.
Central controller: Store employee data, determine whether the employee is allowed to pass according to the swipe card signal, which type of test, and send it to the electrostatic tester, and then drive the three-roll brake mechanism according to the output signal of the electrostatic tester.
1. Main technical parameters
◇ Structure: Frame structure/stainless steel shell
◇ Production process: full CNC laser cutting machine production
◇ Stainless steel thickness :1.5mm
◇ Brake lever length: 500(mm) outside the chassis
◇ Brake rod bearing capacity: 80Kg
◇ Brake lever driving force: 3Kg
◇ Brake lever transmission mode: digital mode
◇ Brake lever steering: one-way, two-way (optional);
◇ Automatic reset function: After opening the gate, the system will automatically lock if not passed within the specified time, and the passing time can be adjusted;
◇ Light prompt: traffic direction indication
◇ The optical hole position working principle, no delay requirement for the input control signal
◇ Working environment: indoor, outdoor (shade)
◇ Temperature: -10℃ ~ 50℃ Relative humidity: ≤90%, no condensation
◇ Sensor card reading bayonet size: with standard mounting bracket, or customized
◇ Opening time: 0.2 seconds
◇ Speed: 30 people/min
◇ Communication interface: standard RS485 interface, distance ≤1200 meters
◇ Input interface: dry contact signal or +12V level signal or DC12V pulse signal with pulse width ≥100ms, driving current ≥10mA;
2. Automatic three-roll brake:
◇ Compatible with IC, ID, magnetic card, bar code card, anti-static and other control equipment
◇ Brake lever running smoothly, low noise
◇ With power off emergency function, brake rod power off automatic drop rod, power automatically on the rod
◇ Control board with counting function, LED digital display function (optional)
◇ Control board with memory function
◇ There are standard input and output interfaces, which are system integrators
3. Semi-automatic three-roll brake:
◇ Compatible with IC, ID, magnetic card, bar code card, anti-static and other control equipment
◇ Brake lever unlock, fast and reliable
◇ With power emergency function, brake rod power off automatically drop rod, power hand lift rod
◇ Control board with counting function, LED digital display function (optional)
◇ Control board with memory function
◇ There are standard input and output interfaces, which are system integrators
4, mechanical three-roll brake:
◇ Unique positioning and reset system: automatic reset, can always keep a rod in a horizontal position
◇ It is a pure mechanical transmission product, no electronic control operation, with simple structure and high reliability
◇ No maintenance and other features, suitable for unidirectional current limit management places
